User interface
Display module
The interconnection between the LCD module and the engine is implemented with a 24-pin board-to-board
connector.
The LCD module does not require any tuning in service.
Keyboard
Table 8 Key signal matrix
GENIO ROW Col_0
(GENIO-39)
Col_0
(GENIO-40)
Col_0
(GENIO-41)
Col_0
(GENIO-42)
32 ROW0 Left SK Left Right SK Up
33 ROW1 Send Right End Down
34 ROW2 1 2 3 Centre
35 ROW3 4 5 6 Vol +
36 ROW4 7 8 9 Vol -
37 ROW5 * 0 # Rewind
RM-352; RM-354
System Module
Page 5 –12 COMPANY CONFIDENTIAL Issue 1
Copyright © 2008 Nokia. All rights reserved.
