CU-4 flash concept with FPS-10
Figure 5 CU-4 flash concept with FPS-10
Type Description
Product specific devices
FS-85 Flash adapter
Other devices
CU-4 Control unit
FPS-10 Flash prommer box
PKD-1/PK-1 SW security device
SS-62 Flash adapter base
SX-4 Smart card
PC with Phoenix service software
Cables
PCS-1 Power cable
XCS-4 Modular cable
Standard USB cable
USB cable
RM-352; RM-354
Service Devices and Service Concepts
Page 2 –18 COMPANY CONFIDENTIAL Issue 1
Copyright © 2008 Nokia. All rights reserved.
