PKD-1 SW security device
SW security device is a piece of hardware enabling the use of the
service software when connected to the parallel (LPT) port of the PC.
Without the device, it is not possible to use the service software.
Printer or any such device can be connected to the PC through the
device if needed.
RJ-184 Rework jig
RJ-184 is a jig used for soldering and as a rework jig for McCoy
Microphones. It is used together with the ST-61 stencil.
RJ-215 Rework jig
RJ-215 is a jig used for soldering and as a rework jig for the engine
module. It is used together with the ST-66 stencil.
RJ-216 Rework jig
RJ-216 is a jig used for soldering and as a rework jig for the engine
module. It is used together with the ST-67 stencil.
RJ-230 Common jig
RJ-230 is a jig used for soldering and as a rework jig for the engine
module.
RM-352; RM-354
Service Devices and Service Concepts
Page 2 –10 COMPANY CONFIDENTIAL Issue 1
Copyright © 2008 Nokia. All rights reserved.
