SS-102 Front camera
removal tool
The front camera removal tool SS-102 is used to remove/attach a front
camera module from/to the camera socket of the phone PWB.
SS-46 Interface adapter
SS-46 acts as an interface adapter between the flash adapter and
FPS-10.
SS-62 Generic flash adapter
base for BB5
• generic base for flash adapters and couplers
• SS-62 equipped with a clip interlock system
• provides standardised interface towards Control Unit
• provides RF connection using galvanic connector or coupler
• multiplexing between USB and FBUS media, controlled by VUSB
SS-93 Blue stick tool
SS-93 is used for general disassembly and assembly tasks.
ST-61 Rework stencil
ST-61 is a rework stencil used with rework jig RJ-184.
RM-352; RM-354
Service Devices and Service Concepts
Page 2 –12 COMPANY CONFIDENTIAL Issue 1
Copyright © 2008 Nokia. All rights reserved.
