Model overview
7 Model overview
7.1 Models of the Nokia FastMile 4G Receiver
7.1 Models of the Nokia FastMile 4G Receiver
A wide range of models are available for the Nokia FastMile 4G Receiver to support
different E-UTRA bands and band combinations for LTE.
All models can be wall-mounted or pole-mounted. If you will be mounting the Nokia
FastMile 4G Receiver on a pole, you will need kit 3TG-00291-AA that contains the
pole adapter for the Nokia FastMile 4G Receiver. Note that pole strapping and wall
fasteners are not provided by Nokia.
Table 5 describes the E-UTRA band and frequency support and the antenna
configurations for each model of the Nokia FastMile 4G Receiver.
Table 5 Models of the Nokia FastMile 4G Receiver
Model
E-UTRA band support and frequencies
Antenna configuration
Model type
4G01-A
• Band 42: TDD, 3400 MHz – 3600 MHz
• Band 43: TDD, 3600 MHz – 3800 MHz
• Band 48: TDD, 3650 MHz – 3700 MHz
Integrated with 15 dBi fixed beamforming
antenna
Compact mono-
band
4G01-B
• Band 42: TDD, 3400 MHz – 3600 MHz
• Band 43: TDD, 3600 MHz – 3800 MHz
• Band 48: TDD, 3650 MHz – 3700 MHz
Integrated with 3x4 dual polarized antenna
array, electronic beam steering +/- 45°
horizontally, and up to 17 dBi peak antenna
gain with beam steering
ABA
4G02-A
• Band 3: FDD, Tx 1710 MHz – 1785 MHz,
Rx 1805 MHz – 1880 MHz
Integrated with 10.5 dBi fixed beamforming
antenna
Compact mono-
band
4G03-A
• Band 7: FDD, Tx 2500 MHz – 2570
MHz, Rx 2620 MHz – 2690 MHz
• Band 38: TDD, 2570 MHz – 2620 MHz
• Band 40: TDD, 2300 MHz – 2400 MHz
• Band 41: TDD, 2496 MHz – 2690 MHz
Integrated with 12.5 dBi fixed beamforming
antenna
Compact mono-
band
4G04-A
• Band 3: FDD, Tx 1710 MHz –
1785 MHz, Rx 1805 MHz – 1880 MHz •
Band 7: FDD, Tx 2500 MHz –
2570 MHz, Rx 2620 MHz – 2690 MHz •
Band 20: FDD, Tx 832 MHz – 862
MHz Rx 791 MHz – 821 MHz
• Band 32: FDD, Rx 1452 MHz –
1496 MHz
Band 7 is integrated with > 11 dBi fixed
beamforming antenna
Band 3 is integrated with > 9 dBi fixed
beamforming antenna
Band 32 is integrated with > 6 dBi fixed
beamforming antenna
Band 20 is integrated with > 3 dBi fixed
beamforming antenna
Compact multi-
band
(1 of 2)
