Management using the Web UI Nokia FastMile 4G Receiver Product Overview
96 3TG-00386-ABAA-TCZZA Issue: 01 DRAFT
DRAFT
• Total number of MB sent on the LTE interface since last FastMile 4G Receiver
restart
• Total number of MB received on the LTE interface since last FastMile 4G
Receiver restart
• Total number of MB sent on the Ethernet interface since last FastMile 4G
Receiver restart
• Total number of MB received on the Ethernet interface since last FastMile 4G
Receiver restart
• Data Model (TR-069)
• Software Version
• Name and corresponding IP address of the configured Access Points
Figure 49 shows an example of the Status screen when the FastMile 4G Receiver is
not connected to a cell.
Figure 49 Example of the Status screen when the FastMile 4G Receiver is not connected to a
cell
Figure 50 shows an example of the Status screen when the FastMile 4G Receiver is
connected to a cell.
