Nokia FastMile 4G Receiver Product Overview Performance information
Issue: 01 DRAFT 3TG-00386-ABAA-TCZZA 59
DRAFT
B20+B32
791 MHz - 821 MHz
+1452 MHz - 1496 MHz
Up to 40 MHz bandwidth
inter band 2CA
(1 of 2)
Bands
Downlinks
Uplinks
Carrier aggregation
support
B7+B32
2620 MHz - 2690 MHz
+1452 MHz - 1496 MHz
Up to 40 MHz bandwidth
inter band 2CA
B3+B7+B20
1805 MHz - 1880 MHz
+2620 MHz - 2690 MHz
+791 MHz - 821 MHz
Up to 60 MHz bandwidth
inter band 3CA
B3+B7+B32
1805 MHz - 1880 MHz
+2620 MHz - 2690 MHz
+1452 MHz - 1496 MHz
Up to 60 MHz bandwidth
inter band 3CA
B3+B20
1805 MHz - 1880 MHz
+791 MHz - 821 MHz
Up to 40 MHz bandwidth
inter band 2CA
B7+B20
2620 MHz - 2690 MHz
+791 MHz - 821 MHz
Up to 40 MHz bandwidth
inter band 2CA
B3+B7
1805 MHz - 1880 MHz
+2620 MHz - 2690 MHz
Up to 40 MHz bandwidth
inter band 2CA
(2 of 2)
Table 14 provides carrier aggregation support information for the Compact multi-
band B1/B3/B7/B38/B40/B41/B20/B28 (Model 4G05-A) of the Nokia FastMile 4G
Receiver.
Table 14 Carrier aggregation support for Model 4G05-A
Band
Downlink
Carrier aggregation support
B1
2110 MHz - 2170 MHz
Up to 40 MHz bandwidth contiguous 2CA
Up to 60 MHz bandwidth contiguous 3CA
B3
1805 MHz - 1880 MHz
Up to 40 MHz bandwidth contiguous 2CA
Up to 60 MHz bandwidth contiguous 3CA
B7
2620 MHz - 2690 MHz
Up to 40 MHz bandwidth contiguous 2CA
Up to 60 MHz bandwidth contiguous 3CA
B38
2570 MHz - 2620 MHz
Up to 40 MHz bandwidth contiguous 2CA
Up to 50 MHz bandwidth contiguous 3CA
B40
2300 MHz - 2400 MHz
Up to 40 MHz bandwidth contiguous 2CA
Up to 60 MHz bandwidth contiguous 3CA
Up to 80 MHz bandwidth contiguous 3CA
