7. Remove both RUBBER STOPPERS with tweezers.
8. Protect the inner side of the lower block.
9. Gently unlock the A-COVER from the backside.
10. Now, shift along the SRT-6 to release the underneath snaps.
11. Do the same procedure at the long sides of the A-COVER.
12. Now, remove the A-COVER by sliding it around 4mm to the
shown direction and then lift it up.
