Nokia 6230 User Manual

20 Copyright © 2004 Nokia
REPLACE THE BACK COVER
10 Slide the back cover into place.
• INSTALL THE MULTIMEDIACARD
Use only MultiMediaCards up to 256 MB with this device. Other memory cards,
such as secure digital (SD) cards, do not fit in the MultiMediaCard card slot and are
not compatible with this device. Using an incompatible memory card may damage
the memory card as well as the phone, and data stored on the incompatible card
may be corrupted.
1 Remove the back cover and battery from
the phone as shown in “Remove the
back cover” on page 18 and “Remove
the battery” on page 18.
2 Place the MultiMediaCard in the card
holder.
Make sure that the MultiMediaCard is
properly inserted and that the
gold-colored contact area on the card is
facing downward and is on the same
side as the gold-colored contacts in the
phone.
3 Replace the battery and back cover as
shown in “Replace the battery” on
page 19 and “Replace the back cover”
on page 20.
6230.ENv1a_9310059.book Page 20 Monday, March 22, 2004 11:54 AM

Nokia 6230 Specifications

General

Display Type	TFT, 65K colors
Resolution	128 x 128 pixels
Internal Memory	6 MB
Battery Type	Removable Li-Ion 850 mAh battery (BL-5C)
Stand-by	Up to 300 h
Talk time	Up to 5 h
Status	Discontinued
Network	GSM
2G bands	GSM 900 / 1800 / 1900
SIM	Mini-SIM
5-way navigation key	Yes
Downloadable wallpapers, screensavers	Yes
Video	Yes
Loudspeaker	Yes
3.5mm jack	No
WLAN	No
Infrared port	Yes
USB	Pop-Port
Messaging	SMS, MMS, Email, Instant Messaging
Browser	WAP 2.0/xHTML
Java	Yes, MIDP 2.0
Predictive text input	Yes
Organizer	Yes
Voice dial	Yes
Brand	Nokia
Weight	97 g (3.42 oz)
Display Size	1.5 inches
Card Slot	MMC
Main Camera	VGA
Announced	2003
GPRS	Class 10
Phonebook	1000 entries
Alert types	Vibration; Downloadable polyphonic ringtones
Games	Yes
Colors	Black
SAR	0.73 W/kg (head)
Dimensions	103 x 44 x 20 mm, 76 cc
Bluetooth	Yes, v1.1
Radio	FM radio
