Nokia 6233 - Module Jig Concept

Item Type Description
2 SS-46 Interface adapter
3 CA-35S Power cable
4 XCS-4 Modular cable
5 FPS-10 Flash prommer box
6 Standard USB cable
7 PKD-1 SW security device
Module jig concept
Module jig concept is meant for BB / RF testing + tuning and for flashing purposes.
Figure 31 Module jig service concept
Item Type Description
1 MJ-91 Module jig
2 CU-4 Control unit
3 FPS-10 Flash prommer box
4 SX-4 Smart card
5 XCS-4 Modular cable
6 PCS-1 DC power cable
RM-123; RM-145
