Service Manual 6290 RM-176 Copyright © 2007 NOKIA Corporation. All rights reserved.
Approved 2.0
MGR
Page
(45)
7. Unlock the snaps of the B-COVER UPPER starting on the
shown side.
8. Expand the B-COVER UPPER from the shown side…
9. …and gently slide the SRT-6 along the edge to unlock the
snaps. Do not twist the SRT-6 to avoid scratching the covers.
10. Do the same on the other side.
11. Remove the B-COVER UPPER.
12. Unlock the snaps of the UI KEYMAT with the SS-93…
