Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
13.Apr.2007
29
Service Manual 6290 RM-176 Copyright © 2007 NOKIA Corporation. All rights reserved.
Approved 2.0
MGR
Page
(45)
19. …secure it by pressing it into position.
20. Open the unit …
21. …and t the KEYMAT into the A-COVER LOWER.
22. Check the correct position of the KEYMAT.
23. Fit the BATTERY COVER.
24. Finally, check that no gaps remain.
