Page #143 background imageLoading...
Page #143 background image
VBAT (Battery voltage)
The BSI line is used to recognize the battery capacity by a battery internal pull down resistor.
Charging
This phone is charged through a separate charger connector.
Charging is controlled by energy management, and external components are needed to protect the baseband
module against EMC, reverse polarity and transient frequency deviation.
Complementary USB charging is supported as well, in case the phone is connected to a PC or to a dedicated
USB charger.
Normal and extreme voltages
Energy management is mainly carried out in the ASIC PEARL/GAZOO. These circuits contain a number of
regulators. In addition there are some external regulators.
In the table below normal and extreme voltages are shown when a BL-4CT battery is used.
Table 13 Nominal voltages
Voltage Voltage [V] Condition
General Conditions
Nominal voltage 4.1
Lower extreme voltage 3.5
Higher extreme voltage (fast
charging) 4.2
HW Shutdown Voltages
Vmstr+ 2.1 ± 0.1 Off to on
Vmstr- 1.9 ± 0.1 On to off
SW Shutdown Voltages
Sw shutdown 3.106 In call
Sw shutdown 3.2 In idle
Min Operating Voltage
Vcoff+ 2.9 ± 0.1 Off to on
Vcoff- 2.7 ± 0.1 On to off
Power key and system power-up
When the battery is placed in the phone the power key circuits are energized. When the power key is pressed,
the system boots up (if an adequate battery voltage is present).
Power down can be initiated by pressing the power key again (the system is powered down with the aid of
SW). The power key is connected to EM ASIC N2200 (Gazoo/Pearl) via PWRONX signal.
RM-598; RM-604
System Module
Issue 1 COMPANY CONFIDENTIAL Page 5 –9
Copyright © 2009 Nokia. All rights reserved.
