7368 ISAM ONT E-240W-A Product Guide Configure an E-240W-A indoor ONT
Issue: 01 3FE-46974-AAAA-TCZZA 113
•
UPnP and DLNA
• voice setting
Procedure 34 Port forwarding configuration
1 Select Application > Port forwarding from the top-level menu in the EPON Home Gateway
window, as shown in Figure 50.
Figure 50 Port forwarding window
Table 36 describes the fields in the port forwarding window.
Table 36 Port forwarding parameters
Field Description
Application Name Choose an application name from the drop-down menu
WAN Port WAN port range
LAN Port LAN port range
Internal Client Choose a connected device from the drop-down menu and enter the associated IP
address
Protocol Choose the port forwarding protocol from the drop-down menu:
• TCP
• UDP
• TCP/UDP
Enable Mapping Select this checkbox to enable mapping
(1 of 2)
