15. BLUETOOTH TEST
Bluetooth test
You need another Bluetooth device (e.g. 6310i) to do a GoNoGo test.
Make sure that Bluetooth is activated in the reference unit. The distance of the devices should be not more than
5m from each other.
Test unit Reference unit, Bluetooth /infrared activated
Settings on the test unit:
• From Desk (Home Menu) Select Contacts
• Select My card
• Select Send
• Select Bluetooth
• Select OK
If needed (for e.g. after a sw-update), enter a name for this device.
• If the Bluetooth is currently of, select Switch on
• select New search
If all Bluetooth devices in range will be displayed, the test is successful!
• Select Cancel
• Select Menu key to reach the Desk (Home Menu)
Note: If the Bluetooth is activated, switch it off!
