Nokia 7710 Service Manual

nokia
CONNECTING PEOPLE
PAGE 17 (25) Approved 1.0
CMO Sales and Marketing Customer Care EMEA
DJk
Service & Support Readiness, Repair Concepts CONFIDENTIAL 13.12.2004
10. LEGEND FOR QUICK TROUBLE SHOOTER
This legend is valid for all parts of the Quick Trouble Shooter
Follow the steps until the problem is solved. If this doesn’t help, you are not authorized to go forward.
Only marked components (e.g. I002
) can be changed.
The start point of repair activities regarding the appeared fault symptoms.
Follow the arrows step by step
Pads or contacts: Check optical and mechanical condition particularly regarding
to corrosion. Clean if necessary.
Measure component for electrical functionality and change, if needed.
(Level 2 only)
Pads or contacts: Check optical and mechanical condition particularly regarding
to corrosion. Clean with ESD brush only, if necessary.
No more actions possible send product to the appropriate service supplier with
higher service level.
Service Manual 7710 Level 1&2 Copyright © 2004 Nokia Corporation. All rights reserved.

Nokia 7710 Specifications

General

Operating System	Symbian OS 7.0s, Series 90 UI
Internal Storage	90 MB
Expandable Storage	MMC, up to 2 GB
Weight	189 g (6.67 oz)
Announced	2004, November
Status	Discontinued
SIM	Mini-SIM
Alert types	Vibration; Downloadable polyphonic, monophonic ringtones
Loudspeaker	Yes
3.5mm jack	No
WLAN	No
GPS	No
Radio	No
USB	Pop-Port
Messaging	SMS, MMS, Email, Instant Messaging
Browser	WAP 2.0/xHTML, HTML
Java	Yes, MIDP 2.0
Stand-by	Up to 240 h
Talk time	Up to 3 h 30 min
Network	GSM 900 / 1800 / 1900
Infrared port	Yes
Display	3.5 inches, 640 x 320 pixels
Camera	1 MP, 1152 x 864 pixels
Battery	Removable Li-Ion 1300 mAh battery (BP-5L)
CPU	150 MHz ARM9
Bluetooth	Yes
