Figure 69. Measurements menu structure
DNT measurements:
0 Display all
1 Noise margins
2 Rx levels
3 Tx levels
4 Attenuations
5 Line voltage
Pair
#
1
2
Line voltage xxV
7
7,0
Noise margins
Pair 1 xxdB
Pair 2 xxdB
7,1
Rx levels
Pair 1 xxdBm
Pair 2 xxdBm
7,2
Tx levels
Pair 1 xxdBm
Pair 2 xxdBm
7,3
Attenuation
Pair 1 xxdB
Pair 2 xxdB
7,4
Line voltage
xxV
7,5
NM
dB
xx
xx
At
dB
xx
xx
Tx
dBm
xx
xx
Rx
dBm
xx
xx
NM = Noise margin
At = Attenuation
