Using Q1 menus
DN01145897 © Nokia Corporation 93 (128)
Issue 2-0 en Nokia Proprietary and Confidential
Figure 70. Statistics menu structure
xx
xx
xx
xx
xx
xx
xx
Port stat absolute:
1 15min periods
2 24h periods
3 Since last reset
Port stat relative:
1 15 min periods
2 24h periods
8
DNT statistics:
1 Port statistics
2 Line statistics
3 System counters
99 Reset all statistics
Port statistics:
1 Interface status
2 Timing slip
3 Relative values
4 Absolute values
5 Reset statistics
8,1,port#
Timing slip:
0 Display
1 Reset counters
8,1,port#,2
8,1,port#,3
8,1,port#,4
8,2
8,3
15 min/24h relative statistics:
PO xxd xxh xxmin xxs
UATR
ESR
SESR
BBER
UATR
ESR
SESR
8,1,port#,3,1
8,1,port#,3,2
8,1,port#,4,1
8,1,port#,4,2
(Rx):
(Rx):
(Rx):
(Rx):
(Tx):
(Tx):
(Tx):
xxxxx
xxxxx
xxxxx
xxxxx
xxxxx
xxxxx
xxxxx
15 min/24h absolute statistics:
PO xxd xxh xxmin xxs
UAT
ES
SES
BBE
UAT
ES
SES
(Rx):
(Rx):
(Rx):
(Rx):
(Tx):
(Tx):
(Tx):
xx
xx
xx
xx
xx
xx
xx
Statistics since last reset:
TT 2d 3h 45min 12s
UAT
ES
SES
BBE
UAT
ES
SES
8,1,port#,4,3
(Rx):
(Rx):
(Rx):
(Rx):
(Tx):
(Tx):
(Tx):
Give period 0 to 100
(0=current, 1=last, 2=prev. etc)
1)
Give period 0 to 100
(0=current, 1=last, 2=prev. etc)
1)
1) You can choose up to 100 15 min
periods or up to 30 24h periods
Port statistics:
Give port number:
1, 2 or 3
8,1
*
* This menu is not displayed in
the single-port version
