Nokia FastMile 5G14-B - Radio - Cellular (WAN-Side)

Technical specifications
74
User Guide
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3TG-02285-AAAA-TCZZA-02
Radio - cellular (WAN-side)
Supported 5G NR channel bandwidths:
5G NR specifications
3GPP Release 15 - 5G NR NSA:
Option 3X and SA: Option 2
Supported 5G NR radio bands:
Sub-6 GHz (FDD):
• n1 2100 (UL: 1920-1980
MHz; DL: 2110-2170 MHz)
• n3 1800 (UL: 1710-1785
MHz; DL: 1805-1880 MHz)
• n5 850 (UL: 869-894 MHz;
DL: 824-849 MHz)
• n7 2600 (UL: 2500-2570
MHz; DL: 2620-2620MHz)
• n8 900 (UL: 880-915 MHz;
DL: 925-960 MHz)
• n20 800 (UL: 832-862 MHz;
DL: 791-821 MHz)
• n28 700 (UL: 703-748 MHz;
DL: 758-803 MHz)
Sub-6 GHz (TDD):
• n38 TD 2600 (2570-2620
MHz)
• n40 TD 2300 (2300-2400
MHz)
• n41 TD 2500 (2496-2690
MHz)
• n78 TD 3500 (3300-3800
MHz)
5G NR antenna gains:
• n78: 4-9 dBi
• n7/n38/n40/n41: 3-6.5 dBi
• n1/n3: 3-4 dBi
• n5/n8/n20/n28: 1-2 dBi
4G/LTE specifications
Supported 4G/LTE radio bands:
FDD:
• B1 (2100 MHz)
• B3 (1800 MHz)
• B5 (850 MHz)
• B7 (2600 MHz)
• B8 (900 MHz)
• B20 (800 MHz)
• B28 (700 MHz)
• B32 (1500 MHz)
TDD:
• B38 (2600 MHz)
• B40 (2300 MHz)
• B41 (2500 MHz)
• B42 (3500 mHz)
4G/LTE antenna gains
• B42: 4-8 dBi
• B1, B3, B7, B32, B38, B40, B41: 3-4 dBi
• B5, B8, B20, B28: 1-2dBi
Note: Actual supported radio frequency (RF) bands may vary in different
regions due to certifications.
