Nokia G-2426G-B - Figure 5-3 G-2426 G-B Indoor ONT Physical Connections (Back) NAR

G
-
2426G
-
B
unit
data
sheet
G-2426G-B interfaces and interface capacity
Nokia
ONT
3FE-49441-ABAA-TCZZA
June
2021
Issue 1
55
Table 5-5 G-2426G-B indoor ONT interface connection capacity
ONT type and
model
Maximum capacity
POTS 10/ 100
BASE-T
10/ 100/ 1000
BASE-T
RF video
(CATV)
MoCA VDSL2 E1/T1 Local craft
GPON
SC/APC
G-2426G-B
1
2 — 4 — — — — — 1
Notes:
1. The G-2426G-B ONTs provide Wi-Fi service that is enabled and disabled using a Wi-Fi on/off switch.
5.5.1 G-2426G-B connections and components
Figure 5-3, “G-2426G-B indoor ONT physical connections (back) NAR” (p. 55) shows the physical
connections for G-2426G-B indoor ONTs. Two USB port is on the side of the ONT.
Figure 5-3 G-2426G-B indoor ONT physical connections (back) NAR
36372
