NSM–3/3D
Service Software Instructions
PAMS Technical Documentation
Page 74
Issue 4 02/2002
 Nokia Mobile Phones Ltd.
Displays path of PPM package file to be flashed.
… button:
Opens Open File dialog, with which the user can select a PPM
package file to be flashed to ME. If the user selects OK button,
the name of selected file is copied to PPM Image edit field.
Usually you should use Market Area list box to select PPM file.
Version in File edit field (read only):
MCU SW version string of the PPM package.
Package Versions edit field (read only):
Lists the file versions of PPM package.
Flash button (ALT+F):
Starts flashing selected files to phone. Before flashing the SW
asks, if the user wants to save all user settings to file (and load
them after flashing). If reading user settings to ME or writing
them to ME failed, Restore Default User Settings dialog is
opened and the user can restore default settings to phone.
NOTE: If settings are saved but flashing fails or for some other
reason setting are not loaded back to phone, the saved set-
tings can be loaded phone later. When settings are saved they
are also copied to files which names are generated from phone
PSN. If settings are not loaded back to phone after flashing
those files are left and found by application when phone is
flashed next time. After successful loading to phone files are
removed.
Close button (ESC):
Closes the dialog box and
does not start flashing.
Erasure Options group:
Erase Defined Area check box:
If it is checked, prommer erases from phone EEPROM area
defined with Low limit and High limit fields. If it is not checked
only new blocks are erased from phone EEPROM. If values in
fields are not valid, then check box is disabled. Checkbox state
is read from flash pack ini–file, from entry EraseDefinedArea.
Low limit edit box (read only):
Hexadecimal value defining low erase limit, value should be
plain hexadecimal without any prefix. Field value is read from
flash pack ini–file, from entry LowEraseLimit.
High limit edit box (read only):
Hexadecimal value defining high erase limit, value should be
plain hexadecimal without any prefix. Field value is read from
flash pack ini–file, from entry HighEraseLimit.
Force D
ownload check box (ALT+D):
