NSM–3/3D
Service Software Instructions
PAMS Technical Documentation
Page 75
Issue 4 02/2002
Nokia Mobile Phones Ltd.
Forces downloading of selected PPM file to a prommer even, if
it already exists there. Can be used to replace a corrupted file
in a prommer with a proper one.
ROM Version Group:
ROM Version edit box:
Shows rom version of flashed phone.
Check button (Alt+A):
Checks connected phone, reads MCU SW and ROM version
from the phone and loads market areas. If application cannot
detect ROM version, the user is shown ROM Version selection
dialog. If application cannot detect phone type, the user is
shown Phone Type Selection dialog.
LPT Port list box (ALT+L):
the user can select parallel port to be used when flashed.
During flashing status dialog is showed. After phone is flashed current
time in PC is set to phone and the user is asked to check that the time is
correct. If flashing succeeded “Flashing completed!” message is shown to
the user, if flashing failed “Flashing failed” message is shown instead.
After flashing phone several self–test are checked or run. If some of those
fail, then Flash Id, factory sets or user settings are not written to phone.
For example if SW Version fails, then MCU SW version does not match
phone HW and the user should flash MCU SW and PPM for correct ROM
version.
Phone Type Selection dialog:
NOTE: This is a screen sample, actual information may differ.
Dialog mode: modal.
Phone Type Selection dialog includes following items:
Phone Type group:
List box:
The user can select phone type.
OK button (ENTER):
The user accepts selected phone type.
