Nokia RM-180 Service Manual

Flash LED HW baseband troubleshooting
Troubleshooting flow
If there are problems in the flash LED driver circuit, the testing procedure is complicated, because the driver
circuit output cannot be reliably measured without the load (LED). Load (LED) is always disconnected from
the output when the phone is disassembled.
RM-180
Nokia Customer Care Camera Module Troubleshooting
Page 8 –26 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.

Nokia RM-180 Specifications

General

Network Technology	GSM
2G bands	GSM 900 / 1800
SIM	Mini-SIM
Display Type	Monochrome graphic
Messaging	SMS
Clock	Yes
Alarm	Yes
Status	Discontinued
Weight	93 g
Resolution	96 x 65 pixels
Call records	10 dialed
Battery Type	Removable Li-Ion
