Service tools
The table below gives a short overview of service tools that can be used for testing, error analysis and repair
of product RM-305; RM-306, refer to various concepts.
ACF-8 Universal power
supply
ACF-8 universal power supply is used to power FPS-8. ACF-8 has 6V DC
and 2.1A output.
AXS-4 Service cable
The AXS-4 D9-D9 service cable is used to connect two 9 pin D
connectors for example between PC and FPS-8.
The cable length is 2 meters.
CA-106DS Easy flash II cable
The cable is used for connecting phone DC port to the flash prommer
FPS-10.
CA-10DS Bi-directional
Parallel Cable
Bi-Directional parallel cable included in FPS-8 sales pack.
RM-305; RM-306
Service Tools
Issue 2 COMPANY CONFIDENTIAL Page 2 –5
Copyright © 2007 Nokia. All rights reserved.
