PKD-1 SW security device
SW security device is a piece of hardware enabling the use of the
service software when connected to the parallel (LPT) port of the PC.
Without the device, it is not possible to use the service software.
Printer or any such device can be connected to the PC through the
device if needed.
RJ-164 Soldering jig
RJ-164 is used for component de-soldering and soldering
SA-41 RF Coupler
SA-41 RF Coupler is used for Go/No-Go test after changing components
in the RF part of the phone.
The SA-41 is mounted on the docking station adapter.
Note: For RF attenuation values, please refer to the Service
bulletin.
SF-10 POS flash adapter
The POS flash adapter SF-10 allows FBUS/MBUS connections for
flashing. Its bottom part is a rubber.
SF-56 POS flash adapter
The POS flash adapter SF-56 allows FBUS/MBUS connections for
flashing. Its bottom part is a clip.
RM-305; RM-306
Service Tools
Issue 2 COMPANY CONFIDENTIAL Page 2 –11
Copyright © 2007 Nokia. All rights reserved.
