SPS-1 Soldering Paste
Spreader
The SPS-1 allows spreading of solder to the LGA components pads over
the rework stencils.
SRT-6 Opening tool
SRT-6 is used to open phone covers.
SS-54 Alignment Jig
Alignment jig is used to efficiently assemble the dome-sheet to the
pone's PWB. The jig is made of EDS proof material.
ST-30 Rework stencil
It is used together with RJ-51 to rework the Front End Module (FEM)
N7700.
RM-305; RM-306
Service Tools
Page 2 –12 COMPANY CONFIDENTIAL Issue 2
Copyright © 2007 Nokia. All rights reserved.
