Nokia RM-307 Service Manual

2505 (RM-307)
Nokia Customer Care
19. Use tweezers to clip Vibrator holder and
pull upward to remove it from the D-Cover.
20. Use tweezers to clip Vibrator and pull
upward to remove it from the D-Cover.
21. Use tweezers to clip DC Jack and pull
upward to remove it from the D-Cover.
22. Use 2mm width “ 一 ” type screw bit press
the hinge inward to remove A-Cover/B-Cover
Assy from the C-Cover.
23. Pull A-Cover/B-Cover Assy away from
C-Cover.
24. Pull FPC Cable connector away from
C-Cover.
Page 28 © 2007 Nokia Corporation Company Confidential Issue 1 04/2007
