Nokia RM-362 User Manual

Table 7 Connector for External Audio Accessories
Pin Signal name Direction Description
5 PLUGDET Input Terminal internal
connection, plug
detection
4 HS EAR L Output Audio output
3 HS EAR R Output Audio output
2 HS MIC Input Multiplexed
microphone audio and
control data
1 HS GND - Ground contact
Interfaces
RF and baseband interfaces
Table 8 AC and DC Characteristics of BB4.0 LiteV2 RF-Base band Digital Signals
Signal
name
From To Para-meter Input characteristics Function
Min Typ Max Unit
TXP1 UPP RF-IC 1 1.38 1.88 V Depends of
the RF design
RFGenOu
t3
GenIO5 0 0 0.4 V
Load
Resistance
10 kW
Load
Capacitanc
e
20 pF
Timing
Accuracy
¼ symbo
l
TXP2 UPP RF-IC 1 1.38 1.88 V Depends of
the RF design
(GenIO6
)
0 0 0.4 V
Load
Resistance
10 kW
Load
Capacitanc
e
20 pF
Timing
Accuracy
¼ symbo
l
RM-362; RM-363
System Module
Page 6 –10 COMPANY CONFIDENTIAL Issue 1
Copyright © 2008 Nokia. All rights reserved.
