CA-99PS Adapter
CA-99PS adapter, 3.5 jack to 5.5 plug.
PCS-1 Power cable
The PCS-1 power cable (DC) is used with a docking station, a module
jig or a control unit to supply a controlled voltage.
XRS-6 RF cable
The RF cable is used to connect, for example, a module repair jig to
the RF measurement equipment.
SMA to N-Connector approximately 610 mm.
Attenuation for:
•
GSM850/900: 0.3+-0.1 dB
•
GSM1800/1900: 0.5+-0.1 dB
•
WCDMA/WLAN: 0.6+-0.1dB
RM-839; RM-840; RM-841
Service Tools and Service Concepts
Issue 1 NOKIA INTERNAL USE ONLY Page 2 – 11
Copyright © 2013 Nokia. All rights reserved.
