Nokia XS-2426G-B User Manual

Table 5-9 XS-2426G-B indoor ONT power consumption specifications
Mnemonic Maximum power
(Not to exceed)
Condition Minimum power Condition
XS-2426G-B 30 W 2 POTS 5REN, 4 1000/100/10
Base-T Ethernet, WI-Fi
operational, USB operational
9.6 W Wi-Fi beacon, other
interface/service not
provisioned
Table 5-10, “XS-2426G-B indoor ONT environmental specifications” (p. 56) lists the environmental
specifications for XS-2426G-B indoor ONT.
Table 5-10 XS-2426G-B indoor ONT environmental specifications
Mounting method Temperature range and humidity Altitude
On desk or shelf Operating: 23°F to 113°F (-5°C to 45°C) ambient
temperature
90% humidity at 40°C
Contact your Nokia technical support representative for
more information
Storage: -4°F to 158°F (-20°C to 70°C)
5.8 XS-2426G-B GEM ports and T-CONTs
Table 5-11, “XS-2426G-B indoor ONT capacity for GEM ports and T-CONTs” (p. 56) lists the
maximum number of supported T-CONTs and GEM ports. See the appropriate release Customer
Release Notes for the most accurate list of supported devices.
Table 5-11 XS-2426G-B indoor ONT capacity for GEM ports and T-CONTs
ONT or MDU Maximum Notes
Package P ONTs
GEM ports per indoor or outdoor ONT 256 256 are present; 254 are available, and 2 are reserved for
multicast and debugging
T-CONTs per indoor or outdoor ONT 32 32 are present; 31 are available, and 1 is reserved for
OMCI
5.9 XS-2426G-B performance monitoring statistics
The following section identifies the supported performance monitoring statistics for the XS-
2426G-B. A check mark indicates the statistic is supported on that ONT. An empty cell indicates the
statistic is not supported. A cell without a check mark indicates the counter is not applicable to that
type of ONT. The following tables are categorized by supported counters types:
•
Table 5-12, “XS-2426G-B ONT generic performance monitoring statistics” (p. 57) provides
statistics for generic ONT type counters
• Table 5-13, “XS-2426G-B ONT ONTL2UNI performance monitoring statistics” (p. 57) provides
statistics for ONTL2UNI type counters
XS-2426G-B unit data sheet
XS-2426G-B GEM ports and T-CONTs
Nokia ONT
Review Review
© 2021 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-49546-AAAA-TCZZA
December 2021
56 Issue 1

Nokia XS-2426G-B Specifications

General

GPON Ports	1
Gigabit Ethernet Ports	4
FXS Ports	2
Power over Ethernet	No
VLAN Support	Yes
Jumbo Frame Support	Yes
Operating Temperature	0°C to 40°C
Humidity	5% to 95% (non-condensing)
Wi-Fi Bands	2.4GHz & 5GHz
Management	TR-069
Power Supply	12 V DC
