INTRODUCTION TO THE DEVICE
1. LCD Display
2. Sensitivity Button
3. Notch Discrimination Button
4. Pinpoint Button
5. LCD Display & Keypad Backlight Button
6. Volume Button
7. Power & Mode Button
Press the button once to turn the device on. To turn
o the device, press and hold it for around 3 seconds.
For a hard reset in case of any unresponsiveness of
the system, press and hold down for about 30 seconds.
8. Speaker
9. Search Coil & Charger Input Socket
10. Wired Headphones Input Socket
11. Search Coil Input Socket
12. Wired Headphones & Charger Input Socket
IMPORTANT! When the connector is not in use, keep
it closed with the cap!
3
5
5
1
2
7
6
5
4
3
10
12
9
11
8
