* Automatic Tuning Sequence *
Step 7
↓
↓↓
↓
⇒
↓
↓↓
↓
Release
ReleaseRelease
Release
⇒
↓
↓↓
↓
Switch
SwitchSwitch
Switch
• Release the auto switch to continue.
Exit cab
Exit cabExit cab
Exit cab
↓
↓↓
↓
⇒
↓
↓↓
↓
push
pushpush
push
⇒
↓
↓↓
↓
boom tip
boom tipboom tip
boom tip
⇒
near to
near tonear to
near to
⇒
↓
↓↓
↓
ground
groundground
ground
⇒
↓
↓↓
↓
&
&&
&
let go
let golet go
let go
• Do not activate any hydraulic functions during this step.
• Exit the cab of the machine and manually push either boom tip near
to the ground for a moment and then let go.
CAUTION: BE SURE TO NOT WALK NEAR THE SENSORS
WHEN APPROACHING THE BOOM. STAY AT LEAST 3
FEET FROM THE SENSOR IN ORDER TO NOT INDUCE
MEASUREMENT ERROR.
Push either boom tip such that the tip moves at least 15 inches (more
if you can).
• Once the panel has detected your sprayer's geometry, the next
screen will appear.
• Press "NO" or press and hold "AUTO" at this screen to accept the
default parameters and continue.
To Next Page
