Version 3/01 Page 11/25
Reading field data:
•
Enter crusher control display (press F1 in main menu).
•
Select LOGBOOK (press F3).
•
Choose field data (press F2).
•
Press F7 to exit.
Key Function Description of function.
F5 Timescale, day <-- Go over to previous time scale.
F6 Timescale, day --> Go over to next time scale.
F7 Close Exit to Choose production data screen.
2.5 Alarms
A warning is indicated by a yellow and an alarm by a red indicator light. Alarm texts are
also marked with red. You get more information by pressing F1. Messages are
acknowledged by pressing F3.
The following details are stored and displayed in conjunction with an alarm or warning:
•
Date and time
•
Type; warning or alarm
•
Description of alarm
You can browse the messages backwards and forwards with the keys F5 and F6. A list
continuing outside the screen at the bottom is indicated by an arrow (V) at the bottom
right corner of the screen. Correspondingly, a list continuing upwards outside the screen
is indicated by an arrow (/\) at the top right corner.
