Measuring current
Figure 24: Current measurement with an ampere meter
Note: An ampere meter measures the average current drawn by the nRF52832 SoC if:
• The average timing for the ampere meter is long (for example, 1 s or more).
• The dynamic range of the ampere meter is wide enough to give accurate measurements from 1
µA to 15 mA.
We recommend that you use a true Root Mean Square (RMS) ampere meter.
4397_500
28
