NordicTrack C 320i User Manual

11
8. Insert the Upright Wire (81) into the bottom of
the right handrail assembly (E) and out of the
front as shown.
Attach the right handrail assembly (E) to the
Right Upright (90) with two 5/16" x 2 1/2" Screws
(28) and two 5/16" Star Washers (11); do not
fully tighten the Screws yet. Make sure not to
pinch the Upright Wire (81).
Then, remove and discard the indicated
screw (D).
28
11
E
90
81
8
D
9. Tighten four #8 x 3/4" Screws (2) into the left and
right handrail assemblies (C, E) and into the Left
and Right Uprights (89, 90).
9
E
C
89
90
2
2

NordicTrack C 320i Specifications

General

Brand	NordicTrack
Model	C 320i
Category	Treadmill
Language	English
