NordicTrack E 7.2 Elliptical User Manual

15
18
18. Orient the Rear Console Cover (80) as shown.
Attach the Rear Console Cover (80) to the
Upright (4) with two M4 x 16mm Screws (101).
Orient the Front Console Cover (79) as shown.
Attach the Front Console Cover (79) around
the Upright (4) by pressing the hooks on the
Rear Console Cover (80) onto the tabs on the
Front Console Cover.
79
4
80
B
119
101
19
19. Plug the Power Adapter (119) into the receptacle
on the frame of the elliptical.
If necessary, plug the Power Adapter (119) into
the Plug Adapter (B).
Note: To plug the Power Adapter (119) into an
outlet, see HOW TO PLUG IN THE POWER
ADAPTER on page 17.
20. Make sure that all parts are properly tightened before you use the elliptical. Note: Extra parts may be
included. Place a mat beneath the elliptical to protect the floor.
