11
11
99
7
11. Have a second person hold the Handlebar (7)
near the Handlebar Carriage (99).
Locate the short wire tie (G) in the Handlebar
Carriage (99). Tie the indicated end of the short
wire tie to the two wires (I) on the Handlebar (7).
Next, pull the other end of the short wire tie
(G) until the two wires (I) are routed through
the Handlebar Carriage (99). Then, untie and
discard the wire tie.
G
I
10
47
68
6
2
10. Tip: Avoid pinching the Main Wire (68) during
this step.
Loosen and pull the Post Knob (47).
Next, insert the Handlebar Post (6) into the
Frame (2), and release the Post Knob (47) into
the lowest adjustment hole (H) in the Handlebar
Post. Then, tighten the Post Knob.
Note: After the exercise bike is assembled, you
can adjust the Handlebar Post (6) to the desired
height.
Avoid pinching the
Main Wire (68)
H
To Next Page
