13
14. Identify the Right Pedal (13).
Using an adjustable wrench, firmly tighten the
Right Pedal (13) clockwise into the Right Crank
Arm (71).
Firmly tighten the Left Pedal (not shown)
counterclockwise into the Left Crank Arm
(not shown). IMPORTANT: You must turn the
Left Pedal counterclockwise to attach it.
Next, adjust the right strap (E) to the desired
position, and press the ends of the strap onto
the tabs (F) on the Right Pedal (13). Adjust the
strap on the Left Pedal (not shown) in the
same way.
13
E
F
14
15
16
71
15. After the exercise bike is assembled, inspect
it to make sure that it is assembled correctly,
that it functions properly, and that all parts
are properly tightened. Extra parts may be
included. Place a mat under the exercise bike to
protect the floor or carpet.
Plug the Power Adapter (82) into the receptacle
on the frame of the exercise bike.
Then, plug the Power Adapter (82) into an
outlet (see HOW TO PLUG IN THE POWER
ADAPTER on page 14).
82
16. IMPORTANT: You must activate your Console
(15) to begin using its exclusive features.
First, press any button on the Console (15) to
turn on the power.
Then, using your smart phone or tablet, go to
iFit.com/activate and follow the instructions to
activate the Console (15).
Note: If you do not have a smart phone or tablet,
use your computer to go to iFit.com/activate for
an alternate way to activate the Console (15). If
you do not have a computer, call Customer Care
(see the front cover of this manual).
15
