6
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you nish all assembly steps.
• Assembly requires only the included tool(s).
• Assembly may be easier if you have a set of
wrenches. To avoid damaging parts, do not use
power tools.
ASSEMBLY
1
2. If there is a shipping support attached to the rear
of the Frame (1), remove the screws from the
shipping support, and discard the screws and
the shipping support.
With the help of another person, place some
packing inserts from the packing material under
the rear of the Frame (1) so that the Frame is
lifted off the floor. Have another person hold
the elliptical to prevent it from moving from
side to side until this step is completed.
Orient the Rear Stabilizer (70) as shown. Attach
the Rear Stabilizer to the Frame (1) with two
M10 x 120mm Screws (84).
Then, remove the packing inserts and lower the
Rear Stabilizer (70).
2
84
70
1
1. Go to my.nordictrack.com on your computer
and register your product.
• documents your ownership
• activates your warranty
• ensures priority customer support if assistance
is ever needed
Note: If you do not have internet access, call
Customer Care (see the front cover of this
manual) and register your product.
