11
7. Raise the Frame (52) to the position shown.
Have a second person hold the Frame until
step 8 is completed.
Orient the Storage Latch (49) so that the large
barrel and the latch knob are in the positions
shown.
Attach the lower end of the Storage Latch (49) to
the Upright (73) with a 3/8" x 2" Bolt (24) and a
3/8" Nut (6).
7
49
Large
Barrel
52
Latch
Knob
73
6
24
8. Attach the upper end of the Storage Latch (49)
to the Frame (52) with a 3/8" x 2" Bolt (24) and a
3/8" Nut (6). Note: It may be necessary to move
the Frame back and forth to align the Storage
Latch with the Frame.
Lower the Frame (52) (see HOW TO LOWER
THE TREADMILL FOR USE on page 23).
8
24
6
49
52
