7
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materialsuntilyounishallassemblysteps.
• After shipping, there may be an oily substance
on the exterior of the treadmill. This is normal. If
there is an oily substance on the treadmill, wipe
it off with a soft cloth and a mild, non-abrasive
cleaner.
• Left parts are marked “L” or “Left” and right parts
are marked “R” or “Right.”
• To identify small parts, see page 6.
• Assembly requires the following tools:
the included hex keys
one adjustable wrench
one Phillips screwdriver
scissors
needlenose pliers
To avoid damaging parts, do not use power tools.
ASSEMBLY
1. Make sure that the power cord is unplugged.
Locate the Upright Wire (70) bundled around the
front of the Base (80). Cut the plastic tie securing
the Upright Wire. Route the Upright Wire out of
the indicated hole.
Press a Base Cap (77) into each side of the
Base (80).
See the inset drawing. Cut the plastic tie near
the Upright Wire (70). Be careful not to dam-
age the Upright Wire.
70
80
Hole
Cut
70
Tie
Cut
77
1
To Next Page
