14
17. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic
on the treadmill decals, remove the plastic. To protect the oor or carpet, place a mat under the treadmill.
Note: Extra hardware may be included. Keep the included hex keys in a secure place; one of the hex keys is
used to adjust the walking belt (see pages 31 and 32).
16. Attach the upper end of the Storage Latch (53)
to the Frame (56) with a 3/8" x 2" Bolt (3) and a
3/8" Nut (12).
See HOW TO LOWER THE TREADMILL FOR
USE on page 29. Lower the Frame (56).
16
53
12
56
3
15. Raise the Frame (56) to the position shown.
Have a second person hold the Frame until
step 16 is completed.
Orient the Storage Latch (53) so that the large
barrel and the latch knob are in the positions
shown.
Attach the lower end of the Storage Latch (53) to
the Base (94) with a 3/8" x 2" Bolt (3) and a 3/8"
Nut (12).
15
53
Large
Barrel
56
Latch
Knob
12
3
94
To Next Page
