9
6. Identify the Left and Right Base Covers (88, 89),
which are marked “Left” and “Right.” Slide the
Left and Right Base Covers onto the Left and
Right Uprights (84, 85) as shown.
89
85
84
88
6
5. Hold the Right Upright (85) against the Base
(29). Partially tighten three 3/8" x 4" Screws (3)
with three 3/8" Star Washers (10) into the Right
Upright and the Base; do not fully tighten the
Screws yet.
85
5
10
3
29
