Air and Fluid Specications
Fluid to
Air Ratio
Max. Air
Pressure
bar
(psi)
Max. Fluid
Working
Pressure
bar (psi)
Fluid Flow, liters/min (gpm)
Cycles per Liter
(Gallon)
Liters (Gallons) per
Cycle
at 15 cpm at 30 cpm at 60 cpm
4:1
7
(100)
28
(400)
2.80
(0.75)
5.70
(1.50)
11.40
(3.00)
5.20
(20.00)
0.195
(0.050)
Operating Sound Levels
Air
Pressure
Strokes Per Minute
20 40 60 80 100
2.7 bar
(40 psi)
0.43 l/sec
(0.91 cfm)
0.88 l/sec
(1.87 cfm)
0.76 l/sec
(2.80 cfm)
1.75 l/sec
(3.70 cfm)
2.22 l/sec
(4.70 cfm)
4.1 bar
(60 psi)
0.71 l/sec
(1.50 cfm)
1.42 l/sec
(3.00 cfm)
2.12 l/sec
(4.50 cfm)
2.83 l/sec
(6.00 cfm)
3.54 l/sec
(7.50 cfm)
5.5 bar
(80 psi)
0.90 l/sec
(1.90 cfm)
1.77 l/sec
(3.75 cfm)
2.64 l/sec
(5.60 cfm)
3.54 l/sec
(7.50 cfm)
4.43 l/sec
(9.40 cfm)
7 bar
(100 psi)
1.06 l/sec
(2.25 cfm)
2.12 l/sec
(4.50 cfm)
3.21 l/sec
(6.80 cfm)
4.25 l/sec
(9.00 cfm)
5.33 l/sec
(11.30 cfm)
Connections
Fluid hose: high pressure airless hose
WARNING:
dampen vibrations.
