14
Part 7580607_01
E 2018 Nordson Corporation
Description and Parts - HDLV - 150L Powder Feed
Hopper
The HDLV- 150L Powder Feed Hopper is used to hold the virgin and
reclaimed powder when using Nordson HDLV powder feed pumps. It comes
fitted with casters and removable lid for easy operator access. Fitted with
level sensors, it a utomatically monitors the powder level and maintains the
required level of powder.
7
Figure 8 HDLV- 150L Hopper assembly
Item Part Number Description Notes
- 7035259 Hopper, 150L - HDLV
1 - Vent Hose Adaptor
2 1070199 In spection Cover
3 - Air supply fitting
4 - HDLV Powder Pick- Up Lance Inlet
5 - Powder Inlet for Sieve Connection
6 7032221 PROBE,LEVEL SENSOR,24VDC ATEX,PNP,90 DEG
7 7033472 FLUID BED,HOPPER,150L
HDLV- 150L Hopper assembly Specifications
Powder Capacity
150 litre
HDLV apertures 2 - Pick- Up Lance (32 guns max)
Dimensions in mm (L x D x H) 1025x600x730 (includes castors and latches)
Capacity 70kg
Fluidising Air Pressure 1.0- 2.7 bar (15- 40 psi)
Fluidising Air Tubing diameter 10 mm (ring main)
