17
Part 7580607_01
E 2018 Nordson Corporation
Description - Magnetic Separator
The Magnetic Separator is used to remove the finest magnetic particles that
could contaminate powder, particularly with porcelain enamel powders.
WARNING: Magnetic - not to be used by operators fitted with a pacemaker
2
1
Figure 11 Magnetic Separator assembly
Item Part Number Description Notes
- 7033471 SEPERATOR,MAGNETIC,SIEVE,E360B
1 1018902 GRATE,TRAMP IRON,3 TUBE,8.5 X6 A
2 1018903 GRATE,TRAMP IRON,4 TUBE,8.5 X6 A
NOTE: Magnets are ordered separately. One set of each item, 1 & 2, are
required for each assembly.
Dimensions
Height
211 mm
Length 225 mm
Depth 174 mm (+ 41 mm for handle)
