18
Part 7580607_01
E 2018 Nordson Corporation
Description - Accumulator
TheAccumulatorisusedtoreceiveandmixbothvirginandreclaimed
powder, prior to entering the sieve. By default, it has usable 8inletswith a
possibility to add more if required. The Accumulator is particularly used with
Porcelain Enamel powders and is capable of handling higher volumes of
powder than the Mini Cyclone.
1
2
3
4
5
6
7
Figure 12 Accumulator assembly
Item Part Number Description Notes
- 7033470 ACCUMULATOR,MINI,SIEVE,E360B,W/4 HOSE BR
1 - Body, Accumulator
2 - Cover, Separator, 16 Inlet, St.St.
3 - Fitting, Pneumatic, Elbow - SMC
4 7033473 BRACKET,SUPPORT,TRANSFER HOSE A
5 - Fitting, G1/2 - 13 mm I/D Hose
6 - Vent, Accumulator
7 - Cap, PVC, Inlet
Note: 4offaresuppliedwith a standard delivery.
