Installation
WARNING: Allow only qualified personnel to perform the following tasks.
Follow the safety instructions in this document and all other related
documentation.
Do not
position the Rotary Sieve & Hopper assembly in an EX- Zone.
NOTE: The ATEX zone for inside the Rotary Sieve & Hopper are according
to the Ex- Drawing supplied with the system. If the unit was supplied alone
(not part of a full system) the details of t he ATEX zone can be found on the
serial number identification plate.
Preparing for Installation
Position the Rotary Sieve & Hopper assembly on a level floor. Secure the
frame to the floor using suitable anchors/bolts. The location must be
according to the general layout drawing supplied by Nordson engineering,
when part of a system.
Electrical Connections
WARNING: Equipment damage may occur if the electrical panel is
connected to any line voltage other than that stated on the identification
plate. Power to the Rotary Sieve Assembly must be supplied from a locking
disconnect switch or breaker. Failure to observe this warning may result in a
severe shock during installation or repair.
Make sure that all electrical cables are correctly rated and suitable for the
ambient temperature of the installation area. Provide adequate fuse/circuit
protection from the power supply. Refer to the foldout wiring diagrams and
schematics at the end of this manual for more information.
Initial start- up should be performed only by a Nordson field engineer or
technician.
Pneumatic Connections
For the connection size, location and volume required please refer to your
Service Requirements drawing or contact your Nordson representative.
Clean, dry, compressed air should be supplied from a refrigerated or
desiccant air dryer and filter/separators. Refer to the Operation section for
compressed air s pecifications.
Note: For information on the Rotary Sieve please refer to technical manual
of AZO.
