Location
The air conditioner should be placed on a firm
foundation to minimize noise and vibration. For
safe and secure positioning, place the unit on a
smooth and level floor strong enough to support
the unit.
The unit has castors to aid movement. The unit
should only be rolled on smooth flat surfaces.
Use caution when rolling on carpet or rug
surfaces. Do not attempt to roll the unit over
objects.
The unit must be placed within reach of a properly
rated grounded socket.
Never place any obstacles around the air inlet or
outlet of the unit.
Allow at least 12” (30cm) of space from the wall
for efficient cooling. See Fig. 6.
Window slider kit installation
Your window slider kit has been designed to fit most
standard “Vertical” and “Horizontal” windows.
However, it may be necessary for you to
improvise/modify some aspects of the installation
procedures for certain types of windows. Please refer
to Fig. 7 & 8 for minimum and maximum window
dimensions.
NOTE: The adjusted length of the window slider kit
can be fixed with a bolt. See Fig. 8a.
NOTE: If the window opening is less than the
recommended minimum length of the window slider
kit, the window slider kit can be modified (or cut) to fit
the window opening. If such a modification is
required, only cut the part that has the exhaust hole.
NEVER CUT OUT THE HOLE IN THE WINDOW
SLIDER KIT.
