Norsup P31V/32 - Electrical Cable Specifications

6.APPENDIX
6.2 Cable specification
(1) Single phase unit
Nameplate maximum current
Phase line
Earth line
MCB
Creepage protector
Signal line
No more than 10A
2×1.5mm
2
1.5mm
2
20A
30mA less than 0.1 sec
n×0.5mm
2
10~16A
2×2.5mm
2
2.5mm
2
32A
30mA less than 0.1 sec
16~25A
2×4mm
2
4mm
2
40A
30mA less than 0.1 sec
25~32A
2×6mm
2
6mm
2
40A
30mA less than 0.1 sec
32~40A
2×10mm
2
10mm
2
63A
30mA less than 0.1 sec
40 ~63A
2×16mm
2
16mm
2
80A
30mA less than 0.1 sec
63~75A
2×25mm
2
25mm
2
100A
30mA less than 0.1 sec
75~101A
2×25mm
2
25mm
2
125A
30mA less than 0.1 sec
101~123A
2×35mm
2
35mm
2
160A
30mA less than 0.1 sec
123~148A
2×50mm
2
50mm
2
225A
30mA less than 0.1 sec
148~186A
2×70mm
2
70mm
2
250A
30mA less than 0.1 sec
186~224A
2×95mm
2
95mm
2
280A
30mA less than 0.1 sec
(2) Three phase unit
Nameplate maximum current
Phase line
Earth line
MCB
Creepage protector
Signal line
No more than 10A
3×1.5mm
2
1.5mm
2
20A
30mA less than 0.1 sec
n×0.5mm
2
10~16A
3×2.5mm
2
2.5mm
2
32A
30mA less than 0.1 sec
16~25A
3×4mm
2
4mm
2
40A
30mA less than 0.1 sec
25~32A
3×6mm
2
6mm
2
40A
30mA less than 0.1 sec
32~40A
3×10mm
2
10mm
2
63A
30mA less than 0.1 sec
40 ~63A
3×16mm
2
16mm
2
80A
30mA less than 0.1 sec
63~75A
3×25mm
2
25mm
2
100A
30mA less than 0.1 sec
75~101A
3×25mm
2
25mm
2
125A
30mA less than 0.1 sec
101~123A
3×35mm
2
35mm
2
160A
30mA less than 0.1 sec
